Magnetic navigation stacker forklift AGV-ES16-RS
AGV-ES16-RS adds an automatic navigation system and a lifting height recognition system on the basis of the Zhongli all-electric stacker, which can realize the automatic stacking of goods on the rack, and at the same time, it can guide the navigation according to the defined route with high accuracy. This vehicle type can be used in a vertical warehouse to realize the automation of cargo handling and stacking.
Touch screen, warning light, MP3 player, anti-collision bar, travel switch,
Collision avoidance sensor, magnetic navigation sensor, card reader
（1）Stand-alone version: Customers can design their own path, through the touch
The site is set on the screen, and the forklift runs according to the pre-set requirements. This
The method does not require a network, and the cost is low;
（2）Central control software scheduling: set up the route and assign on the control computer
The forklift goes to the required site for loading and unloading.
| model | AGV-ES16-RS | ||
| project | Parameter Description | ||
| model | AGV-ES16-RS | Guidance form | Magnetic stripe/laser |
| Load | 1600kg | Load center distance | 600mm |
| Carrying length | 690mm | Wheelbase | 1145mm |
| Weight (including battery) | 985kg | Axle load, fully loaded drive end/load end | 1642/843kg |
| Axle load, no-load drive end/load end | 676/309kg | Tyre type, driving wheel/loading wheel | PU/PU |
| Drive wheel size (diameter×width) | Φ230×75mm | Bearing wheel size (diameter×width) | Φ85×70mm |
| Balance wheel size (diameter×width) | Φ130×55mm | Number of driving wheels, balance wheels/loading wheels | 1X+1/4mm |
| The lowest height after the mast is lowered | 1962mm | Free lift height | 100mm |
| Maximum lifting height of mast | 2700mm | The height of the whole vehicle when the mast is lifted the highest | 3400mm |
| The height of the fork surface after the fork is lowered | 88mm | Vehicle length | 2220mm |
| Vehicle width | 900mm | Fork size | 60/200/1150mm |
| The tray is 1200 wide x 1000 long aisle width | 685mm | Outer width of fork | 2650mm |
| The tray is 800 wide x 1200 long aisle width | 2620mm | Turning radius | 1800mm |
| Parking accuracy, magnetic stripe/laser | 20/10mm | Lifting accuracy, magnetic stripe/laser | 10/5mm |
| Walking speed, magnetic stripe/laser | 0.7~1/1~1.5m/s | Lifting speed, fully loaded/unloaded | 0.18/0.22m/s |
| Braking type | electromagnetic | Obstacle avoidance type | Machinery & Electronics |
| Drive motor rated power S2 60 minutes | 1.5kw | Lifting motor rated power S3 15% | 3kw |
| Battery voltage/capacity | 24/210V/Ah | Drive control type | 24/210V/Ah |
| Steering type | electronic | Noise level | 74 |
